Net Weight
0.01 kg
Bend radius protection/trumpet flare
-
Colour
Other
Degree of protection (IP)
IP66
Explosion-tested version
-
Flat cable coupling
-
For Ex-Zone dust
None
For Ex-zone gas
None
Glass-fibre reinforced
-
Halogen free
+
Hexagon angular dimension
26.5 mm
Material
Plastic
Material quality
Polyamide (PA)
Model
Straight
Multi seal area
-
Nominal thread size metric/PG
20
Pitch thread
1.5 mm
RAL-number
2003
Separable screw gland
-
Shock resistant
+
Suitable for cable diameter
6.5 .. 13.5 mm
Surface protection
Untreated
Thread length
8 mm
Thread type
Metric
Type of sealing
Sealing ring
With locknut
+
With strain relief
+
Working temperature
-25 .. 70 °C
Wrench width
24 mm
