Net Weight
0.603 kg
Colour
Orange
Dimensions
130X130X77 mm
Halogen free
Yes
Height
130 mm
Ingress Protection
IP65/66
Length
77 mm
Mounting method
Surface mounted
Width
130 mm
With lid
Yes
Castable
-
Casting compound included
-
Circuit integrity
E90
Colour
Orange
Cover
Not transparent
Cover attachment
Screwed
Cover model
Other
Degree of protection (IP)
IP66
Depth
77 mm
Equipped with
Clamp
Explosion-tested version
-
For Ex-Zone dust
None
For Ex-zone gas
None
For tube diameter
Other
Halogen free
+
Inlet from the rear
-
Length
130 mm
Material
Plastic
Max. conductor cross section
6 mm²
Mounting method
Wall-/ceiling mounting
Number of inlets
7
Rated insulation voltage Ui
400 V
Sealable
+
Shape
Square
Surface protection
Other
Tackable
-
Type of housing feed-through
Preembossing
Weatherproof
-
Width
130 mm
With screening
-
Working temperature
-25 .. 40 °C
