Net Weight
0.115 kg
Colour
White
Dimensions
88X88X50 mm
Halogen free
Yes
Height
88 mm
Ingress Protection
IP55
Length
50 mm
Mounting method
Surface mounted
Width
88 mm
With lid
Yes
Castable
-
Casting compound included
-
Circuit integrity
None
Colour
White
Cover
Not transparent
Cover attachment
Screwed
Cover model
Other
Degree of protection (IP)
IP55
Depth
50 mm
Equipped with
Clamp
Explosion-tested version
-
For Ex-Zone dust
None
For Ex-zone gas
None
For tube diameter
Other
Halogen free
+
Inlet from the rear
+
Length
88 mm
Material
Plastic
Max. conductor cross section
4 mm²
Mounting method
Wall-/ceiling mounting
Number of inlets
11
Rated insulation voltage Ui
690 V
Sealable
+
Shape
Square
Surface protection
Untreated
Tackable
-
Type of housing feed-through
Seal membrane
Weatherproof
-
Width
88 mm
With screening
-
Working temperature
-25 .. 40 °C
