Net Weight
0.148 kg
Colour
White
Dimensions
98X98X55 mm
Halogen free
Yes
Height
98 mm
Ingress Protection
IP55
Length
55 mm
Mounting method
Surface mounted
Width
98 mm
With lid
Yes
Castable
-
Casting compound included
-
Circuit integrity
None
Colour
White
Cover
Not transparent
Cover attachment
Screwed
Cover model
Other
Degree of protection (IP)
IP55
Depth
55 mm
Equipped with
Clamp
Explosion-tested version
-
For Ex-Zone dust
None
For Ex-zone gas
None
For tube diameter
Other
Halogen free
+
Inlet from the rear
+
Length
98 mm
Material
Plastic
Max. conductor cross section
4 mm²
Mounting method
Wall-/ceiling mounting
Number of inlets
11
Rated insulation voltage Ui
690 V
Sealable
+
Shape
Square
Surface protection
Untreated
Tackable
-
Type of housing feed-through
Seal membrane
Weatherproof
-
Width
98 mm
With screening
-
Working temperature
-25 .. 40 °C
