Net Weight
2.186 kg
Colour
Gray
Dimensions
295X225X122 mm
Halogen free
Yes
Height
225 mm
Ingress Protection
IP66
Length
122 mm
Mounting method
Surface mounted
Width
295 mm
With lid
Yes
Castable
-
Casting compound included
-
Circuit integrity
None
Colour
Grey
Cover
Not transparent
Cover attachment
Screwed
Cover model
Other
Degree of protection (IP)
IP66
Depth
122 mm
Equipped with
Clamp
Explosion-tested version
-
For Ex-Zone dust
None
For Ex-zone gas
None
For tube diameter
Other
Halogen free
+
Inlet from the rear
+
Length
295 mm
Material
Plastic
Max. conductor cross section
35 mm²
Mounting method
Wall-/ceiling mounting
Number of inlets
12
Rated insulation voltage Ui
690 V
Sealable
+
Shape
Rectangular
Surface protection
Untreated
Tackable
-
Type of housing feed-through
Preembossing
Weatherproof
-
Width
225 mm
With screening
-
Working temperature
-25 .. 40 °C
