Out Of Stock
Notify me when its in stockNet Weight
0.137 Kg
Colour
Gray
Dimensions
93x93x62 Mm
Halogen Free
Yes
Height
93 Mm
Ingress Protection
Ip66/67
Length
62 Mm
Mounting Method
Surface Mounted
Width
93 Mm
With Lid
Yes
Castable
-
Casting Compound Included
-
Circuit Integrity
None
Colour
Grey
Cover
Not Transparent
Cover Attachment
Screwed
Cover Model
Other
Degree Of Protection (ip)
Ip66/ip67/ip69
Depth
62 Mm
Equipped With
Clamp
Explosion-tested Version
-
For Ex-zone Dust
None
For Ex-zone Gas
None
For Tube Diameter
Other
Halogen Free
+
Inlet From The Rear
-
Length
93 Mm
Material
Plastic
Max. Conductor Cross Section
4 Mm²
Mounting Method
Wall-/ceiling Mounting
Number Of Inlets
7
Rated Insulation Voltage Ui
690 V
Sealable
+
Shape
Square
Surface Protection
Untreated
Tackable
-
Type Of Housing Feed-through
Preembossing
Weatherproof
+
Width
93 Mm
With Screening
-
Working Temperature
-25 .. 70 °c
