Net Weight
0.927 kg
Colour
Black
Dimensions
255X205X122 mm
Halogen free
Yes
Height
205 mm
Ingress Protection
IP66/67
Length
122 mm
Mounting method
Surface mounted
Width
255 mm
With lid
Yes
Castable
-
Casting compound included
-
Circuit integrity
None
Colour
Black
Cover
Not transparent
Cover attachment
Screwed
Cover model
Other
Degree of protection (IP)
IP66/IP67/IP69
Depth
112 mm
Equipped with
Clamp
Explosion-tested version
-
For Ex-Zone dust
None
For Ex-zone gas
None
For tube diameter
Other
Halogen free
+
Inlet from the rear
+
Length
255 mm
Material
Plastic
Max. conductor cross section
35 mm²
Mounting method
Wall-/ceiling mounting
Number of inlets
10
Rated insulation voltage Ui
690 V
Sealable
+
Shape
Rectangular
Surface protection
Untreated
Tackable
-
Type of housing feed-through
Preembossing
Weatherproof
+
Width
205 mm
With screening
-
Working temperature
-25 .. 70 °C
