Net Weight
0.143 kg
Colour
Black
Dimensions
93X93X62 mm
Halogen free
Yes
Height
92 mm
Ingress Protection
IP66
Length
93 mm
Mounting method
Surface mounted
UV resistant
Yes
Width
62 mm
With lid
Yes
Castable
-
Casting compound included
-
Circuit integrity
None
Colour
Black
Cover attachment
Screwed
Cover model
Blind cover
Degree of protection (IP)
IP66
Depth
62 mm
Equipped with
Clamp
Explosion-tested version
+
For Ex-Zone dust
22
For Ex-zone gas
2
Halogen free
+
Inlet from the rear
-
Length
93 mm
Material
Plastic
Max. conductor cross section
4 mm²
Mounting method
Wall-/ceiling mounting
Number of inlets
7
Rated insulation voltage Ui
690 V
Sealable
-
Shape
Square
Surface protection
Untreated
Tackable
-
Type of housing feed-through
Other
Weatherproof
+
Width
93 mm
With screening
-
Working temperature
-20 .. 40 °C
