Net Weight
1.302 kg
Colour
Gray
Dimensions
130X130X77 mm
Halogen free
Yes
Height
130 mm
Ingress Protection
IP68
Length
77 mm
Mounting method
Surface mounted
Width
130 mm
With lid
Yes
Castable
+
Casting compound included
+
Circuit integrity
None
Colour
Black
Cover
Not transparent
Cover attachment
Screwed
Cover model
Other
Degree of protection (IP)
IP68
Depth
77 mm
Equipped with
Clamp
Explosion-tested version
-
For Ex-Zone dust
None
For Ex-zone gas
None
For tube diameter
Other
Halogen free
+
Inlet from the rear
+
Length
130 mm
Material
Plastic
Max. conductor cross section
6 mm²
Mounting method
Wall-/ceiling mounting
Number of inlets
7
Rated insulation voltage Ui
690 V
Sealable
+
Shape
Square
Surface protection
Untreated
Tackable
-
Type of housing feed-through
Preembossing
Weatherproof
+
Width
130 mm
With screening
-
Working temperature
-25 .. 70 °C
